MODELS | | | | |
CUTTING AREA | 72 in. (184 cm) wide x 126 in. (320 cm) long; up to 164 ft. (50 m) long in multi panel | | | |
MEDIA WIDTH | Up to 75 in. (190 cm) | | | |
MULTI PANEL* | 1968 in. (5000 cm) *Media clamps and roll-feed and/or conveyor belt system are required |
REPEATABILITY | Within ± 0.05 mm on plots |
ACCURACY | 0.05 % of move or 0.05 mm, whichever is greater |
SPEED | Up to 39 in./sec (1000 mm/sec) |
ACCELERATION | Up to 1 G |
CLEARANCE* | 1.9 in. (5 cm) *Distance between vacuum table and Y-beam. Not taking into account the thickness of a cutting matt or conveyor belt |
MAXIMUM ALLOWED FORCES | Vertical: 200 Newton, Horizontal: 200 Newton |
MAXIMUM TABLE LOAD | 10 lb/ft2 (50 kg/m²) |
CONNECTIVITY | USB |
POWER REQUIREMENTS | 3 Phase 208V+N or 3 Phase 230V or 3 Phase 400V+N |
DIMENSIONS | 137 x 161 x 48 in. (349 x 410 x 122 cm) | | | |
WEIGHT | 3700 lbs (1680 kg) | | | |
